Brand: Tornos
Model: DELTA 12/5
Year: 2012
Serial: 51100175
Brand: Tornos
Model: DELTA 12/5
Year: 2012
Serial: 51100175

Caracteristics & Equipment

Caracteristics
- Number of axes : 5 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 12 [mm] - Max. machining length : 170 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 12 [mm] - Z stroke - Spindle speeds : 12000 [rpm] - Spindle power : 2.2 [kW] - C axis indexing precision : 1 [°] - Number of guide bush holders : 1 GUIDE BUSH HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 7000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 11 [kW] WEIGHT & DIMENSIONS - Machine floor space : 1640 x 1200 [mm] - Machine height : 1725 [mm] - Machine weight : 1950 [kg]
Equipment
- CNC : Fanuc Oi TD - Rotating guide bush - Parts catcher - Parts conveying strip - Ejection of workpiece - Chips conveyor : Mayfran - Coolant tank * with high-pressure pump : 15 [bars] - Bar loader : FMB
PDF datasheet to download:

Description
