Brand: Citizen
Model: C16 VIIA
Year: 2007
Serial: X13243
Brand: Citizen
Model: C16 VIIA
Year: 2007
Serial: X13243

Caracteristics & Equipment

Caracteristics

- Number of axes : 7
- Number of spindles : 2
MAIN SPINDLE
- Max. bar diameter : 16 [mm]
- Travel : 205 [mm]
- Spindle speeds : 10000 [rpm]
- C axis indexing precision : 0.001 [°]
COUNTER-SPINDLE
- Max. bar diameter : 16 [mm]
- Spindle speeds : 10000 [rpm]
- C axis indexing precision : 1 [°]
GUIDE BUSH HOLDER 1
- Number of positions : 9
- Number of motorized positions : 4
END ATTACHMENT
- Number of positions : 6
SECONDARY OPERATION
- Number of positions : 6
POWER SUPPLY
- Supply voltage : 400 [V]
WEIGHT & DIMENSIONS
- Machine floor space : 2269X1160 [mm]
- Machine height : 1693 [mm]
- Machine weight : 1750 [kg]
Equipment

- CNC : Mitsubishi MELDAS
- Rotating guide bush
- Parts catcher
- Parts conveying strip
- Ejection of workpiece
- Coolant tank
- Number of turning tool holders : 4
- Number of fixed tool holders : 5
