- number of spindles : 8
- number of turning slides : 8
- number of longitudinal stations : 8
- maximum bar passage : round Ø 22 [mm]
- maximum bar passage : hexagonal 19 [mm]
- maximum bar passage : square 15 [mm]
- max. bar feed length : 60 [mm]
- number of spindle speeds : 20
- spindle speed : 620 to 6035 [rpm]
- number of camshaft speeds : 24
- max. production : 1-50 [parts/min]
- cross slide travel : 30 [mm]
- max. independent feed stroke : 50 [mm]
- main motor power : 10 [CV]
- weight : 4,700 [kg]
Equipment
- counter-spindle with brake
- counter-operation device
- foot + barrel
- IEMCA PRA 40/33F bar feeder
- chip conveyor
